CAS Number:
75-35-4
Sum Formula:
C2H2Cl2
Molar Mass:
97 g/mol
German Synonyms:
Vinylidenchlorid | 1,1-Dichlorethylen | 1,1-Dichlorethen
English Synonyms:
1,1-Dichloroethylene | 1,1-Dichloroethene
EC Index Number:
602-025-00-8
EC Number:
200-864-0
Temperature Class:
T1
Explosion Group:
IIA
Disclaimer: The CLP/GHS classification is not regularly updated in Chemsafe. For up-to-date information, please use the ECHA database. ( https://echa.europa.eu/en/information-on-chemicals )
GHS Hazard and Category:
- Flam. Liq. 1: flammable liquids, category 1
- Carc. 2: carcinogenicity, category 2
- Acute Tox. 4: acute toxicity by inhalation, category 4
GHS Pictogram:
GHS Signal Word:
Danger
GHS Hazard Statement:
- H224: Extremely flammable liquid and vapour.
- H351: Suspected of causing cancer
. - H332: Harmful if inhaled.
Antoine parameters
1
1987
Stephenson, R.M.; Malanowski, S.
6.10046 kPa
UTI: 137-817-9737/0-39
Bibliographic data
| Author | Stephenson, R.M.; Malanowski, S. |
| Year | 1987 |
| Title | Handbook of The Thermodynamics of Organic Compounds |
| Publisher | Elsevier; New York, Amsterdam, London |
| Language | ENGL |
Boiling point
1
1941
Berger, H.
1013.25 hPa
37 °C
UTI: 15-817-9726/0-39
| Line no | Boiling temperature | Pressure |
|---|---|---|
|
|
|
| 1 | 37 °C | 1013.25 hPa |
Bibliographic data
| Title | Brennbare Gase, Flüssigkeiten und feste Stoffe |
| Author | Berger, H. |
| Year | 1941 |
| Publisher | Edmund Stein u. Co. |
| Publisher City | Potsdam |
| Language | GERM |
2
1950
1013.25 hPa
37 °C
UTI: 1-817-9703/0-39
| Line no | Boiling temperature | Pressure |
|---|---|---|
|
|
|
| 1 | 37 °C | 1013.25 hPa |
Bibliographic data
| Title | Loss Prevention Bulletin No. 36.10: Properties of Flammable Liquids, Gases and Solids |
| Year | 1950 |
| Journal Title | The Factory Mutual Engineering Division;Boston, Ma |
| Publisher | The Factory Mutual Engineering Division |
| Publisher City | Boston |
| Language | ENGL |
3
1950
PTB
1013.25 hPa
37 °C
UTI: 8-817-9713/0-39
| Line no | Boiling temperature | Pressure |
|---|---|---|
|
|
|
| 1 | 37 °C | 1013.25 hPa |
Bibliographic data
| Author | PTB |
| Year | 1950 |
| Title | Tabelle des Labors III-B |
| Database | PTB |
| Publisher | PTB, Labor III-B; Braunschweig |
| Language | GERM |
4
1951
Oehley, E.
1013.25 hPa
34 °C ... 37 °C
UTI: 13-817-9720/0-39
| Line no | Boiling temperature | Pressure |
|---|---|---|
|
|
|
| 1 | 34 °C ... 37 °C | 1013.25 hPa |
Bibliographic data
| Title | Stoffdaten |
| Author | Oehley, E. |
| Year | 1951 |
| Publisher | Farbwerke Hoechst, Techn. Abt. Farben-Gruppe |
| Language | GERM |
5
1963
Nabert, K.; Schön, G.
1013.25 hPa
32 °C
UTI: 1000-817-9755/0-39
| Line no | Boiling temperature | Pressure |
|---|---|---|
|
|
|
| 1 | 32 °C | 1013.25 hPa |
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
6
1994
1013.25 hPa
37 °C
UTI: 16-817-9733/0-39
| Line no | Boiling temperature | Pressure |
|---|---|---|
|
|
|
| 1 | 37 °C | 1013.25 hPa |
Bibliographic data
| Year | 1994 |
| Title | Fire-hazard Properties of certain Flammable Liquids, Gases and Volatile Solids |
| Publisher | National Fire Protection Association |
| Publisher City | Boston |
| Language | ENGL |
Density
1
1941
Berger, H.
1013.25 hPa
20 °C
1.25 g/cm3
UTI: 15-817-9727/0-39
| Line no | Density | Temperature | Pressure |
|---|---|---|---|
|
|
|
|
| 1 | 1.25 g/cm3 | 20 °C | 1013.25 hPa |
Bibliographic data
| Title | Brennbare Gase, Flüssigkeiten und feste Stoffe |
| Author | Berger, H. |
| Year | 1941 |
| Publisher | Edmund Stein u. Co. |
| Publisher City | Potsdam |
| Language | GERM |
2
1950
1013.25 hPa
20 °C
1.25 g/cm3
UTI: 1-817-9704/0-39
| Line no | Density | Temperature | Pressure |
|---|---|---|---|
|
|
|
|
| 1 | 1.25 g/cm3 | 20 °C | 1013.25 hPa |
Bibliographic data
| Title | Loss Prevention Bulletin No. 36.10: Properties of Flammable Liquids, Gases and Solids |
| Year | 1950 |
| Journal Title | The Factory Mutual Engineering Division;Boston, Ma |
| Publisher | The Factory Mutual Engineering Division |
| Publisher City | Boston |
| Language | ENGL |
3
1950
PTB
1013.25 hPa
20 °C
1.25 g/cm3
UTI: 8-817-9714/0-39
| Line no | Density | Temperature | Pressure |
|---|---|---|---|
|
|
|
|
| 1 | 1.25 g/cm3 | 20 °C | 1013.25 hPa |
Bibliographic data
| Author | PTB |
| Year | 1950 |
| Title | Tabelle des Labors III-B |
| Database | PTB |
| Publisher | PTB, Labor III-B; Braunschweig |
| Language | GERM |
4
1951
Oehley, E.
1013.25 hPa
20 °C
1.25 g/cm3
UTI: 13-817-9721/0-39
| Line no | Density | Temperature | Pressure |
|---|---|---|---|
|
|
|
|
| 1 | 1.25 g/cm3 | 20 °C | 1013.25 hPa |
Bibliographic data
| Title | Stoffdaten |
| Author | Oehley, E. |
| Year | 1951 |
| Publisher | Farbwerke Hoechst, Techn. Abt. Farben-Gruppe |
| Language | GERM |
5
1963
Nabert, K.; Schön, G.
1013.25 hPa
20 °C
1.25 g/cm3
UTI: 1000-817-9756/0-39
| Line no | Density | Temperature | Pressure |
|---|---|---|---|
|
|
|
|
| 1 | 1.25 g/cm3 | 20 °C | 1013.25 hPa |
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
Melting point
1
1951
Oehley, E.
-80.5 °C
UTI: 13-817-9719/0-39
2
1963
Nabert, K.; Schön, G.
1013.25 hPa
-122 °C
UTI: 1000-817-9759/0-39
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
Relative gas density
1
1941
Berger, H.
3.35
UTI: 15-817-9728/0-39
2
1946
Freytag, H.
3.4
UTI: 6-817-9710/0-39
| Line no | Relative gas density |
|---|---|
|
|
| 1 | 3.4 |
Bibliographic data
| Title | Merkblatt über Kennzahlen brennbarer Gase und Dämpfe |
| Author | Freytag, H. |
| Year | 1946 |
| Publisher | Magistrat von Gross-Berlin, Abteilung für Arbeit, Hauptamt für Arbeitsschutz |
| Publisher City | Berlin |
| Language | GERM |
3
1950
3.35
UTI: 1-817-9705/0-39
| Line no | Relative gas density |
|---|---|
|
|
| 1 | 3.35 |
Bibliographic data
| Title | Loss Prevention Bulletin No. 36.10: Properties of Flammable Liquids, Gases and Solids |
| Year | 1950 |
| Journal Title | The Factory Mutual Engineering Division;Boston, Ma |
| Publisher | The Factory Mutual Engineering Division |
| Publisher City | Boston |
| Language | ENGL |
4
1950
PTB
3.35
UTI: 8-817-9715/0-39
5
1963
Nabert, K.; Schön, G.
3.35
UTI: 1000-817-9757/0-39
| Line no | Relative gas density |
|---|---|
|
|
| 1 | 3.35 |
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
Solubility in water
1
2009
Physikalisch-Technische Bundesanstalt (PTB)
25 °C
3.4 g/l
UTI: 228-817-9752/0-39
| Line no | Solubility in water | Temperature |
|---|---|---|
|
|
|
| 1 | 3.4 g/l | 25 °C |
Bibliographic data
| Author | Physikalisch-Technische Bundesanstalt (PTB) |
| Year | 2009 |
| Title | Wasserlöslichkeit |
| Database | PTB |
| Publisher | Datenbank PTB-Lab. 3.43 |
| Language | GERM |
- The oxidizing agent is air with an oxygen content of 20.95 % by volume. In the data base it is usually not specified as mixture component. Exceptions are highlighted.
- Pressure values are absolute, not gauge pressures.
- Impurities can strongly influence characteristic safety data, particulary if the properties of the impurity considerably deviate from the respective properties of the pure substance.
- Safety characteristics are only displayed if evaluated data are available.
- Values can be cited by using the UTI number of the table (Uniform Table Identifier).
- Color Codes: recommended value no recommendation do not use value
Autoignition Temperature
1
1963
Nabert, K.; Schön, G.
530 °C
UTI: 1000-817-9758/0-39
| Line no | Autoignition Temperature |
|---|---|
|
|
| 1 | 530 °C [A] [1] |
| [A] DIN 51794: Testing of mineral oil hydrocarbons - Determination of ignition temperature; measurements are technically identical to those of ISO/IEC 80079-20-1 but results are treated differently. |
| [1] stabilized with 600 ppm hydrochinone monomethylether |
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
2
1941
Berger, H.
458 °C
UTI: 15-817-9732/0-39
3
1948
Scott, G.S; Jones, G.W.; Scott, F.E.
441 °C
UTI: 26-817-9734/0-39
| Line no | Autoignition Temperature |
|---|---|
|
|
| 1 | 441 °C |
Bibliographic data
| Title | Determination of Ignition Temperatures of Combustible Liquids and Gases |
| Author | Scott, G.S; Jones, G.W.; Scott, F.E. |
| Year | 1948 |
| Journal Title | Anal. Chem. |
| Volume | 20 |
| Issue | 3 |
| Pages | 238-241 |
| Publisher | Anal. Chem. |
| Language | ENGL |
4
1950
458 °C
UTI: 1-817-9709/0-39
| Line no | Autoignition Temperature |
|---|---|
|
|
| 1 | 458 °C |
Bibliographic data
| Title | Loss Prevention Bulletin No. 36.10: Properties of Flammable Liquids, Gases and Solids |
| Year | 1950 |
| Journal Title | The Factory Mutual Engineering Division;Boston, Ma |
| Publisher | The Factory Mutual Engineering Division |
| Publisher City | Boston |
| Language | ENGL |
5
1951
Oehley, E.
458 °C
UTI: 13-817-9725/0-39
Flash point
1
1963
Nabert, K.; Schön, G.
-25 °C
UTI: 1000-817-9753/0-39
| Line no | Flash point |
|---|---|
|
|
| 1 | -25 °C |
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
2
1941
Berger, H.
14 °C
UTI: 15-817-9729/0-39
3
1950
14 °C
UTI: 1-817-9706/0-39
| Line no | Flash point |
|---|---|
|
|
| 1 | 14 °C |
Bibliographic data
| Title | Loss Prevention Bulletin No. 36.10: Properties of Flammable Liquids, Gases and Solids |
| Year | 1950 |
| Journal Title | The Factory Mutual Engineering Division;Boston, Ma |
| Publisher | The Factory Mutual Engineering Division |
| Publisher City | Boston |
| Language | ENGL |
4
1950
PTB
14 °C
UTI: 8-817-9716/0-39
Explosion limits
Lower explosion limit
1
1963
Nabert, K.; Schön, G.
6.5 Vol% ± 10 %
UTI: 1000-817-9760/0-39
| Line no | Lower explosion limit |
|---|---|
|
|
| 1 | 6.5 Vol% ± 10 % [1] |
| 2 | 260 g/m3 ± 10 % [1] ⚠ |
| [1] stabilized with 600 ppm hydrochinone monomethylether |
| ⚠ The reference for the specification in g/m3 is the molar volume at 20 °C |
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
2
1941
Berger, H.
5.6 Vol%
UTI: 15-817-9730/0-39
3
1946
Freytag, H.
226 g/m3
UTI: 6-817-9711/0-39
| Line no | Lower explosion limit |
|---|---|
|
|
| 1 | 226 g/m3 ⚠ |
| ⚠ The reference for the specification in g/m3 is the molar volume at 20 °C |
Bibliographic data
| Title | Merkblatt über Kennzahlen brennbarer Gase und Dämpfe |
| Author | Freytag, H. |
| Year | 1946 |
| Publisher | Magistrat von Gross-Berlin, Abteilung für Arbeit, Hauptamt für Arbeitsschutz |
| Publisher City | Berlin |
| Language | GERM |
4
1950
5.6 Vol%
UTI: 1-817-9707/0-39
| Line no | Lower explosion limit |
|---|---|
|
|
| 1 | 5.6 Vol% |
Bibliographic data
| Title | Loss Prevention Bulletin No. 36.10: Properties of Flammable Liquids, Gases and Solids |
| Year | 1950 |
| Journal Title | The Factory Mutual Engineering Division;Boston, Ma |
| Publisher | The Factory Mutual Engineering Division |
| Publisher City | Boston |
| Language | ENGL |
5
1950
PTB
5.6 Vol%
UTI: 8-817-9717/0-39
Upper explosion limit
1
1963
Nabert, K.; Schön, G.
15 Vol% ± 5 %
UTI: 1000-817-9761/0-39
| Line no | Upper explosion limit |
|---|---|
|
|
| 1 | 15 Vol% ± 5 % [1] |
| 2 | 600 g/m3 ± 5 % [1] ⚠ |
| [1] stabilized with 600 ppm hydrochinone monomethylether |
| ⚠ The reference for the specification in g/m3 is the molar volume at 20 °C |
Bibliographic data
| Author | Nabert, K.; Schön, G. |
| Year | 1963 |
| Title | Sicherheitstechnische Kennzahlen brennbarer Gase und Dämpfe (mit 6. Nachtrag) |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Abstract English | Safety values of about 1000 flammable gases and vapors: Explosion limits, ignition temperatures, flash points, explosion pressures. |
| Language | GERM |
2
1941
Berger, H.
13 Vol%
UTI: 15-817-9731/0-39
3
1946
Freytag, H.
525 g/m3
UTI: 6-817-9712/0-39
| Line no | Upper explosion limit |
|---|---|
|
|
| 1 | 525 g/m3 ⚠ |
| ⚠ The reference for the specification in g/m3 is the molar volume at 20 °C |
Bibliographic data
| Title | Merkblatt über Kennzahlen brennbarer Gase und Dämpfe |
| Author | Freytag, H. |
| Year | 1946 |
| Publisher | Magistrat von Gross-Berlin, Abteilung für Arbeit, Hauptamt für Arbeitsschutz |
| Publisher City | Berlin |
| Language | GERM |
4
1950
11.4 Vol%
UTI: 1-817-9708/0-39
| Line no | Upper explosion limit |
|---|---|
|
|
| 1 | 11.4 Vol% |
Bibliographic data
| Title | Loss Prevention Bulletin No. 36.10: Properties of Flammable Liquids, Gases and Solids |
| Year | 1950 |
| Journal Title | The Factory Mutual Engineering Division;Boston, Ma |
| Publisher | The Factory Mutual Engineering Division |
| Publisher City | Boston |
| Language | ENGL |
5
1950
PTB
13 Vol%
UTI: 8-817-9718/0-39
Maximum experimental safe gap
1
1992
Nabert, K.; Schön, G.; Redeker, T.
3.91 mm
UTI: 1050-817-9762/0-39
| Line no | Maximum experimental safe gap |
|---|---|
|
|
| 1 | 3.91 mm |
Bibliographic data
| Author | Nabert, K.; Schön, G.; Redeker, T. |
| Year | 1992 |
| Title | Sicherheitstechnische Kenngrößen brennbarer Gase und Dämpfe |
| Publisher | Deutscher Eichverlag |
| Publisher City | Braunschweig |
| Language | GERM |
Stoichiometric fraction of combustible substance in mixture with air
1
2005
Physikalisch-Technische Bundesanstalt (PTB)
9.5 Mol%
UTI: 220-817-9751/0-39
| Line no | Stoichiometric fraction of combustible substance in mixture with air |
|---|---|
|
|
| 1 | 9.5 Mol% |
Bibliographic data
| Author | Physikalisch-Technische Bundesanstalt (PTB) |
| Year | 2005 |
| Title | Berechnete molare stöchiometrische Brenngasanteile in Luft (c_stoech) |
| Database | PTB |
| Publisher | Datenbank PTB-Lab. 3.43 |
| Language | GERM |
Loading, Please wait....
- External Links:
- GESTIS
- BAM Dangerous Goods Database
